5 Inch Two Way Wall Mount Speaker(3.75W-7.5W-15W-30W)

5 Inch Two Way Wall Mount Speaker(3.75W-7.5W-15W-30W)

NV-PASP-WSP-PW282

Description

The NV-PASP-WSP-PW282 is an active ceiling speaker designed for a hotel room, which offers an economical solution for hotels and entertainment applications. TV, laptop, or DVD player outputs could be easily fed into this speaker.

The built-in 5” speaker driver is designed for wide frequency response 130-15kHz, the power output of 5W is enough for a standard hotel room. The metal grille, metal baffle, and metal back can are painted in attractive RAL9016 white color. Its spring clamp makes the easy and secure installation.

It is an ideal economical choice for industrial and commercial applications in hotel, school, office, and factory where background music and paging is needed.

Features

  • 4”/5”/6” two-way wall mount speaker
  • Economy range speaker of excellent sound quality
  • 4 power taps at 100V output
  • Both 100V and 8ohm outputs selector
  • Fast installation by U shaped mounting bracket
  • The 360-degree rotatable mounting bracket could be supplied at the request
  • 100V speaker output
  • A waterproof version of aluminum grille could be made at the request
  • The crossover could be added at the request
  • Commercial use for background music and paging system



Specifications



Model NV-PASP-WSP-PW282
Power Taps @100V 3.75W, 7.5W, 15W, 30W
Power Taps @70V 1.9W, 3.75W, 7.5W, 15W, 30W
Transformer Impedance 2.6KΩ/1.3KΩ/670Ω/330Ω/165Ω
Input 70V/100V/8Ω
SPL(1W/1M) 92dB
Max. SPL (Rated W/1M) 107dB
Frequency Response (-10dB) 125-18KHz
Finish Baffle: ABS, Black/White  Grille: Steel, Black/White
Speaker Driver 5″ x1    1.5″x 1
Dimensions 248 x185 x182mm
Weight 2.7kg
Mounting With mounting bracket fixed by screw
