NV-ADA-MIX-M33

NV-ADA-MIX-M33

NV-ADA-MIX-M33

Features



* 3 MIC inputs, 2 AUX inputs.

* 3 MIC volume control, 2 AUX volume control.

* With priority, MIC1 input is prior to other audio inputs.

* Separate treble and bass adjustment knob.

* One MIC2 / AUX1 selector switch, one MIC3 / AUX2 selector switch.

* Two types of power output: 4 ohms constant resistance, 8 ohms output, and constant

voltage 70V, 100V output.

* Single-channel rated power 35W output.

Specifications



Model NV-ADA-MIX-M33 NV-ADA-MIX-M34
Rated Power Output 35W 60W
Speaker Outputs 70V, 100V & 4~8Ω
Input Sensitivity & Impedance MIC 1, 2, 3: 5mV/600Ω
MIC2: 775mV/10KΩ
AUX2: 350mV/10KΩ
Output Sensitivity & Impedance MIX OUT: 1V/470Ω
Tone Bass: ±10dB at 100Hz
Treble: ±10dB at 10KHz
Frequency Response 50Hz~16KHz (+1dB, -3dB)
S/N Ratio MIC 1, 2, 3: 66dB, AUX 1, 2: 80dB
THD Less than 0.5% at 1KHz, 1/3 rated power
Crosstalk ≤50dB
Cooling Fan automatically start up when temp reaches 55℃
Protection High temp, overload & short-circuit
Power Supply ~110V-230V 50/60Hz
Power Consumption 60W 100W
Weight 3Kg 3.5Kg
Dimensions 484 x 335 x 88mm 484 x 335 x 88mm
Finish Panel: aluminum plate, black
Case: SPCC Panel
